Toyota Hiace offers quality, engine durability and reliability. The flexibility of the cargo space allows versatility of items carried on board along with robust suspension and enhanced safety. Functional yet refine, the Hiace breaks new ground in design, both inside and out.

Categories: ,
  1. General Details

    The fifth-generation HiAce appeared in 2005 as a wide long-wheelbase wagon, wide super-long-wheelbase high-roof “Grand Cabin”, long-wheelbase van, long-wheelbase high-roof van and a wide super-long-wheelbase high-roof van. In this generation the gear lever has been moved to the dashboard to enable easier movement in the cabin. Five-speed manual and four-speed automatic transmissions are available.

    Most models use a four-cylinder DOHC engine, in a variety of forms, a 1TR-FE 2,000 cc or 2TR-FE 2,700 cc petrol engine, or a 2KD-FTV 2,500 cc or 1KD-FTV 3,000 cc D-4D turbo diesel engine. Two of these engines are available in Malaysia, the 2.5 L turbo diesel, offered in a choice of panel van or window van; and the 2.7 L petrol, that comes only in the window van option. At least some general export market HiAces are powered by the 5L-E 3,000 cc diesel engine.

    In Japan, Toyota’s internet-enhanced GPS and vehicle telematics service called G-Book was made an option on all trim packages for both private and commercial uses.

    The fifth-generation HiAce was launched in the Philippines on June 13, 2005, with D-4D variants, Commuter and GL Grandia, both with manual transmission. In March 2006, the new top-of-the-line HiAce Super Grandia was launched, being the first ever HiAce in the Philippines with a standard automatic transmission.

    The 2.5 and 3.0-litre turbodiesel engines have a maximum output of 75 kW at 3,600 rpm and 80 kW at 3,000 rpm respectively and maximum torque of 260 Nm at 1,600–2,400 rpm and 286 Nm at 1,200–1,600 rpm respectively. The 2.7 L petrol engine has a maximum output of 111 kW at 4,800 rpm and a maximum torque of 241 Nm at 3,800 rpm.

    On Japan’s list of the most commonly stolen vehicles the HiAce currently resides in first place. Because of a lack of a theft immobilizer, it is fairly easy to steal a HiAce, as opposed to much more valuable SUVs and sports cars, which have more sophisticated theft deterrent systems.


    The second generation series H200 of RegiusAce was completely restyled and is currently in production. Transmission choices are a 5-speed manual transmission or a 4-speed automatic, with the gearshift lever integrated into the instrument panel so as to allow front seat passengers access to the rear of the vehicle from the inside. A moderate restyle was completed November 2005.

  2. Techical Info
    Model 2KD-FTV
    Type 4-cylinder, DOHC, 16-valve D-4D Turbo Diesel
    Displacement, cc 2,494
    Transmission 5-speed Manual
    Fuel Supply System Direct Injection Common Rail
    Max. Output, kW(PS)/rpm 75(102)/3,600
    Max. Torque, Nm(kg-m)/rpm 260(26.5)/1,600-2,400
    Cargo, Length 2,930 mm
    Cargo, Width 1,545 mm
    Cargo, Height 1,335 mm
    Wheelbase 2,570 mm
    Tread, Front 1,470 mm
    Tread, Rear 1,465 mm
    Weight, Kerb 1,770 kg
    Weight, Gross 2,800 kg
    Min. Turning Radius 5.0 m
    Ground Clearance 195 mm
    Fuel Tank Capacity 70 litre
    Suspension, Front Double Wishbone with Torsion Bar
    Suspension, Rear Leaf Spring
    Gear Ratio, 1st 4.313
    Gear Ratio, 2nd 2.330
    Gear Ratio, 3rd 1.436
    Gear Ratio, 4th 1.000
    Gear Ratio, 5th 0.838
    Gear Ratio, Reverse 4.220
    Brakes, Front Ventilated Disc
    Brakes, Rear Drum
    Tyres and Rims 195R15C(With Wheel Cap)


    Headlamps Halogen Multi-reflector
    Radiator Grille Silver
    Front Bumper Black
    Mudguards With(4-pieces)
     Outside Temperature Display With
    Steering Wheel 4-spoke Urethane
     Air-Conditioner Manual/Front
     Power Windows, Driverr & Front Passenger With(Driver Side Auto Up/Down with Jam Protection)
     Audio System 1-DIN Head Unit CD Player with Tuner, MP3, AUX-Jack, USB and 2 Speakers
     Seats, Material Fabric(Front Seats Only)
     Seating Capacity 2


    Anti-lock Braking System(ABS) With
    Load Sensing Proportioning & Bypass Valve(LSP & BV) With
    High Mount Stop Lamp With
    Reverse Sensors With
     SRS Airbags 2(Driver and Front Passenger)
    GOA Body With
     Seat Belts, Front 3-point ELR with Pretensioner x 2
    Safe Brake Pedal With
     Security System 2 Remote Control Keys, Siren and Auto Door Lock
     Portable Tyre Pump Optional
