| Features | 3.5L |
|---|---|
| Engine | |
| Model | 2GR-FKS |
| Type | V6, 24V DOHC with VVT-iW (intake), VVT-i (exhaust) |
| Displacement (cc) | 3,456 |
| Max. Output kW(PS) / rpm | 221 (300) / 6,600 |
| Max. Torque Nm / rpm | 361 / 4,600 |
| Transmission | |
| Type | 8-speed Automatic with Sequential Shifter |
| Chassis | |
| Suspension (Front) | MacPherson Strut with Stabiliser |
| Suspension (Rear) | Multi-link Double Wishbone |
| Tyres and Rims | 235/50 R18, Alloy |
| Spare Tyre | Temporary Tyre (T155/80 D17) |
| Dimensions And Weight | |
| Overall Length (mm) | 4,945 |
| Overall Width (mm) | 1,850 |
| Overall Height (mm) | 1,895 |
| Wheelbase (mm) | 3,000 |
| Front Tread (mm) | 1,575 |
| Rear Tread (mm) | 1,600 |
| Kerb Weight (kg) | 2,135 |
| Gross Vehicle Weight | 2,660 |
| Fuel Tank Capacity (Litre) | 75 |
| Min. Turning Radius (m) | 5.8 |
| Ground Clearance (mm) | 160 |
| Exterior | |
| Headlamps | LED with Auto Levelling, Cornering Lamps and Daytime Running Lights |
| Front Sequential Turn Signal Lamps | With |
| Rear Sequential Turn Signal Lamps | With |
| Front Fog Lamps and Driving Lamps | With (LED) |
| Rear Combination Lamps | LED with Rear Fog Lamps |
| Rear Spoiler | With Integrated LED High Mount Stop Lamp |
| Outside Rear View Mirrors | Power Foldable, Memory and Signal Lamp |
| Sunroof and Moonroof | With (Twin Moonroof) |
| Wipers (Front/Rear) | Front: Auto with Rain Sensor, Rear: Manual |
| Interior | |
| Drive Mode | With ECO Drive Mode |
| Steering (Type) | 4-spoke Leather-wrapped (Metal Brown Wood Grain) |
| Steering (Switches) | Audio, Adapt. Cruise Control & Lane Tracing Assist |
| Steering (Tilt and Telescopic Adjustable) | With |
| Meter Combination | Optitron |
| Multi-Information Display (MID) | With 4.2" (TFT) |
| Electro Multi Vision (EMV) | Without |
| Wireless Charger | With |
| Ceiling Illumination | With (LED) |
| Smart Entry and Start System | With (Smart Key for Driver, Passenger and Power Back Door) |
| Air Conditioning | Front and Rear (Auto with nanoe™) |
| Inside Rear View Mirror | Full Display Mirror |
| Interior Lamps | Front and Rear Personal Lamps, Glove Box Lamps, Door Courtesy Lamps and Luggage Room Lamps |
| Reading Lamps | With |
| Sunshade | With (Manual) |
| Seats (Material) | Leather (Beige) |
| Seats (Front) | Power Seat (with Ottoman for Passenger, and Seat Air-conditioning) |
| Rear Seats (First Row) | Captain Seats (with Power Recline and Ottoman) |
| Rear Seats (Second Row) | 50:50 Split with Space Up |
| Audio System | Display Audio with 9" Capacitive Touch Screen, Apple CarPlay™ & Android Auto™ Connectivity*, Wi-Fi, Voice Recognition, USB & Bluetooth® |
| Audio System Speaker | 8 |
| Rear Seat Entertainment | Roof Mounted Monitor (10.2" display) |
| Panoramic View Monitor (PVM) | With |
| Front Digital Video Recorder (DVR) | With |
| Rear Digital Video Recorder (DVR) | With |
| Safety | |
| Pre-collision System (PCS) | With |
| Lane Departure Alert (LDA) | With Steering Assist & Lane Tracing Assist (LTA) |
| Dynamic Radar Cruise Control (DRCC) | With (All Speeds) |
| Automatic High Beam (AHB) | With |
| Anti-lock Brake System (ABS) | With Electronic Brake-force Distribution (EBD) and Brake Assit (BA) |
| Vehicle Stability Control (VSC) | With Traction Control (TRC) |
| Electric Parking Brake (EPB) with Brake Hold | With |
| Hill-Start Assist Control (HAC) | With |
| Blind Spot Monitor (BSM) | With |
| Rear Cross Traffic Alert (RCTA) | Without |
| Parking Sensors with Parking Support Brake | With (Front and Rear) |
| Tyre Pressure Monitoring System (TPMS) | With (With Individual Tyre Readout) |
| SRS Airbags | 7 (Driver, Front passenger, Side, Curtain & Driver's Knee) |
| ISOFIX | With |
| Security | |
| Alarm | Immobiliser, Siren with Back-up Battery & Cabin Sensor |
| Toyota Premium Security and Solar Film | With |
| Vehicle Telematics System (VTS) | With |
ALPHARD
EXTERIOR
- Automatic LED Headlamps with Sequential Turn Signal
Powerful LED headlamps, cornering lamps and daytime running lights vastly enhance visibility.
Actual vehicle may vary from image show
- LED Rear Combination Lamps
The dynamic design of the LED rear combination lamps and the sequential turn signal accentuate your presence, day and night.
Actual vehicle may vary from image shown
- Power Back Door
Easily access the cargo area with a single touch of a button.
Actual vehicle may vary from image shown
- Power Sliding Doors
Offers both left and right-side access with the added safety of obstruction detection to help prevent accidental closure.
Actual vehicle may vary from image shown
INTERIOR
- LED Ceiling Illumination
Atmospheric 16 dazzling colour-options that exude sophistication and style.
Actual vehicle may vary from image shown.
- Full Display Mirror
The rear-view mirror displays objects and other vehicles clearly from the reverse camera. Without obstruction from seated passengers, this improves safety while reversing.
Actual vehicle may vary from image shown.
- 3-Zone Air Conditioning with nanoe™
Zoned cooling with plasmacluster filtration for pure, clean air.
Actual vehicle may vary from image shown.
- Rear Seat Entertainment
A 13.3-inch HD image display gives passengers an intense entertainment experience.
- Smart Entry & Start System
Open/close sliding doors and back doors with smart key and overhead console for easier entry and exit.
Actual vehicle may vary from image shown.
PERFORMANCE
- New 3.5L V6 Engine
The 3.5 litre V6 engine with VVT-iW has the ability to provide an exciting driving exeperience. Providing strong power and torque for ultimate driving experience and feel with smooth acceleration and performance.
2GR-FKS
V6, 24V DOHC with VVT-iW (intake), VVT-i (exhaust)
Max Power: 221kW (300PS) / 6,600 rpm
Max Torque: 361Nm / 4,600 rpm - New 8-Speed Automatic with Sequential Shifter
Excellent transmission efficiency and power performance for smooth acceleration. It serves to improve drivability, enhance starting performance, quietness and gives outstanding fuel economy. - Auto Start Stop System
Automatically stops the engine when vehicle is stationary for enhanced fuel economy. As soon as the brake pedal is released, the engine restarts immediately.
SAFETY
- Pre-Collision System (PCS)
Avoids or mitigates frontal collisions by alerting the driver and automatically applying the brakes when there is a risk of collision. - Lane Departure Alert (LDA)
Alerts and assists when you are out of the lane unintentionally. Less swaying, smoother driving. - Lane Tracing Assist (LTA)
Keeps the vehicle centered either by detecting the lane or the preceding vehicle. - Dynamic Radar Cruise Control (DRCC) for All SpeedsMaintain a safe distance with preceding vehicle and brakes automatically when the car ahead stops.
- Automatic High Beam (AHB)
Automatically switches between high beam and low beam as needed to provide maximum road visibility. - Tyre Pressure Monitoring System (TPMS)Displays real-time tire pressure information via multi-information display (MID). Alerts driver when tyre pressure is below ideal level.
- Electric Parking Brake (EPB) with Brake HoldKeeps the vehicle stationary on flat roads with a simple button. Automatically releases during acceleration.
- Blind Spot Monitor (BSM)Outer mirror lights up that indicates that vehicles are in your blind spot.
- Front and Rear Digital Video Recoder (DVR)HD recorder that passively records when vehicle is in use. G-sensor automatically engages the recorder before a collision.
- Panoramic View Monitor (PVM)360° view that allows you to be aware of hazards surrounding your vehicle during parking.
- SRS AirbagsDriver, front passenger, side, curtain and driver’s knee airbags provide complete protection for driver and passengers in the event of a collision.
- Hill-Start Assist Control (HAC)Sustains brake pressure to prevent vehicle from rolling backwards during an incline. Also active when vehicle is in reverse gear
- Vehicle Stability Control (VSC) and Traction Control (TRC)VSC prevents side skids and helps stabilise the vehicle when turning on a curve. TRC will applies the brakes or slowdown the engine to regulate spinning and ensure proper contact of tires.
- Parking Support Brake (PKSB)Applies brakes and drive force control if a collision is likely to happen during the parking process.
CONNECTIVI-T
- Wireless Charger
Offers convenient charging for Qi** standard-compliant devices, without the use of a cable.
- Apple Carplay & Android Auto-ready Connectivity*
9-inch touch screen display with real-time navigation and music options. Selectable via built-in controls or smartphone.
- Vehicle Telematics System (VTS)
An integrated system that monitors and shares your vehicle’s real-time location through a mobile app.
SAFETY
- 5-Year Warranty
5 years warranty from the date of first registration with unlimited mileage.
Interior Colour Options
- Beige Interior With Metal Brown Wood Trim
Optional Accessories
- Toyota Auto Tag**
BREEZE THROUGH TOLL GATES
Developed exclusively for Toyota, the Toyota Auto Tag fits secure and discreetly in a concealed location* and requires no batteries. A balance display with low credit warning is also included.
*Fitment location varies by model.
**Touch n’ Go card not included with the device.
